Plan 1809

Home Shop1-4Plan 1809
Enlarge Images

Plan 1809

$0.00

Plan Package Info Click Here

Please review our shipping options before choosing a shipping method. Shipping is calculated per plan, and not per total order.

Need plans faster? Consider our PDF or CAD options. You’ll receive the plans faster, and there is no shipping charge.

Categories: 1-4, CARRIAGE HOUSES, ML-3 ($70), RRR-2 ($75).
Share
  • Description

Description

Three car garage apartment plan features two bedrooms, two baths, fireplace and a covered deck on the side.

Details

Beds

2

Sqft

1135

Baths Full

2

Levels

2

Sqft Floors

First Floor:71

Second Floor:1064

Exterior Wall

2x6

Roof Framing

Truss

House Dimensions

Width: 46'0"

Depth: 28'0"

Approx. Height: 26'8"

Roof Pitch

6/12 Main

8/12 Front Gable

Ceiling Height

First Floor 9-0

Second Floor 8-0

Features

Foundation

Footing and Foundation Wall

Garage

Three car+
Front-entry
Garage Apartment

Bedroom Features

Upstairs master bedroom
Walk-in closet

Kitchen Features

Breakfast area/nook

Interior Features

Laundry
Open floor plan
Family room

Exterior Features

Deck

Special Features

Fireplace
