Plan 1013

Home Shop1-4Plan 1013
Enlarge Images

Plan 1013

$0.00

Plan Package Info Click Here

Please review our shipping options before choosing a shipping method. Shipping is calculated per plan, and not per total order.

Need plans faster? Consider our PDF or CAD options. You’ll receive the plans faster, and there is no shipping charge.

Categories: 1-4, 2x6-2 ($75), CARRIAGE HOUSES, ML-3 ($70), RRR-2 ($75).
Share
  • Description

Description

If you are looking for a simple, economical carriage house plan with curb appeal and a smart layout, this is worth a look. Above the two garage stalls is a garage apartment accessible by exterior stairs. The open floor plan is a lot like a studio apartment with just a little more privacy. This would be a perfect auxiliary dwelling unit (ADU) for rental income.

Details

Beds

1

Sqft

1172

Levels

2

Sqft Floors

Garage Area:616

Second Floor:511

Exterior Wall

2x4

Roof Framing

Truss

House Dimensions

Width: 32'0"

Depth: 22'0"

Approx. Height: 23'6"

Roof Pitch

12/12 Main Roof

10/12 Front Gable

Ceiling Height

First Floor 8-0

Second Floor 8-0

Features

Foundation

Footing and Foundation Wall

Garage

Two car
Front-entry
Garage Apartment

Kitchen Features

Breakfast area/nook

Interior Features

Open floor plan

Similar Plans

Plan 2402 Select options View Plan

Plan 2402

1 Beds

728 Sqft
1 Baths
$0.00
Plan 2803 Select options View Plan

Plan 2803

1 Beds

598 Sqft
1 Baths
$0.00
Plan 2821 Select options View Plan

Plan 2821

1 Beds

741 Sqft
1 Baths
$0.00
Plan 1808 Select options View Plan

Plan 1808

1 Beds

849 Sqft
1 Baths
$0.00
